Mechanical Lithotripter

Shomei’s Strategy – LithoCrushV

Shomei Ryozawa, MD

Professor and Chairman, Department of Gastroenterology,
Saitama Medical University International Medical Center

Minimize Incision

EST is always the first choice. We keep the incision area for EST at the requisite minimum level (high frequency setting: ESG-100 pulse cut slow 30 W). We apply EPBD when EST appears too risky – for example, patients with oagulopathies, patients taking oral antithrombotic drugs, patients with an extremely small papilla, patients with periampullary diverticulum and patients with surgically altered anatomy.



In general, however, EST is indicated for almost all cases. EPLBD is indicated for large and multiple stones with bile duct dilatation that are difficult to treat by EST and EPBD alone. We normally perform EST before EPLBD. The precut technique are used after conventional methods of biliary cannulation and the pancreatic guidewire-assisted technique have failed.

Device Selection Criterion

The basket is our preferred choice when dealing with stones. We use the 8-wire spiral basket for small stones under 5 mm and sludge, the 8-wire FlowerBasketV for stones from 5 to 8 mm, the 4-wire TetraCatchV for stones from 8 to 10 mm, and the lithotripsy basket (LithoCrushV) for stones over 10 mm.


In situations where the basket catheter has difficulty grasping the stones – with small stones, intrahepatic stones, or a pocket-shaped distal bile duct, for example – we use the retrieval balloon catheter.

Cases Where Lithotripsy has Been Used

The best way to perform EPLBD is to dilate the duct at low pressure. This helps minimize the loads on and risks to the duodenal papilla and bile duct. In our opinion, the low-pressure setting of the StoneMasterV is best suited for this purpose.



When using StoneMasterV previously, we have always found dilation to be more than adequate and have never experienced any problems when performing a procedure. We also believe that low-pressure dilation even with a large-size 18 mm-diameter balloon can support safer EPLBD procedures.

Using the LithoCrushV

The first choice is the wire-guided type (BML-V442QR-30), which is the easiest to use and offers excellent access. Before introduction of the wire-guided type, it was very difficult to guide the retrieval basket to the bile duct. While the guidewire and basket are installed in parallel on some wire-guided models, they are coaxial on the LithoCrushV, which makes insertion remarkably easy.



In cases where CT imaging shows that the stone may be difficult to grasp, we use the hard-wire type (BML-V242QR-30), which has more coils than the standard type.



Because the extra coils provide excellent expansion force, switching to the hard-wire type may make retrieval possible in cases where it is difficult to grasp the stones during a procedure.



The LithoCrush line also includes two standard wire type models with a sheath slide mechanism.

Stone Retrieval Technique

The standard retrieval technique is to expand the basket above the stones, then shaking the basket a little at a time to grasp the stones (see endoscopic and radiological images below).


The LithoCrushV also incorporates a “basket rotation function”, which can be used when the standard method does not appear to be working. Even during use of the wire-guided type, the rotation facility can be used by withdrawing the guidewire.


Occasionally, it may be difficult to grasp stones in the hepatic portal region or intrahepatic bile duct. In this case, withdrawing the guidewire before approach may facilitate extraction.

BML-V442QR-30 (Wire-guided hard type)

Endoscopic image

Endoscopic image

Radiological image

Preventing Basket Deformation

Many doctors believe that it is not necessary to close (tighten) the basket fully. We share that belief. If the stones have been crushed before the basket has fully closed, there is no reason to tighten the basket any further. This also seems to help prevent deformation of the basket (see diagram below).
